Operating Panel (HMI)
Operating Panel (HMI)
HMI
Special Parameters of the Panel
This menu »Device Parameter/HMI« is used to define the contrast of the display, the maximum admissible edit time
and the menu language (after expiry of which, all unsaved parameter changes will be rejected).
Direct Commands of the Panel
Parameter Description Setting range Default Menu path
Contrast Contrast 0 - 100% 50% [Device Para
/HMI]
Reset Options If the »C« key is pressed while the device is
performing a cold restart a general Reset
Dialog appears on the screen. Select which
options shall be available with this dialog.
Fact.def., "PW
rst",
Only
"Fact.defaults",
Reset deact.
Fact.def., "PW
rst"
[Device Para
/Security
/Miscellaneous]
Smart view via
USB
Activate (allow) or inactivate (disallow) the
Smart view access via the USB interface.
inactive,
active
active [Device Para
/Security
/
Communication
]
Smart view via
Eth
Activate (allow) or inactivate (disallow) the
Smart view access via the Ethernet
interface.
inactive,
active
active [Device Para
/Security
/
Communication
]
Global Protection Parameters of the Panel
Parameter Description Setting range Default Menu path
t-max
Edit/Access
If no other key(s) is pressed at the panel,
after expiration of this time, all cached
(changed) parameters are canceled. The
device access will be locked by falling back
into Read-only level Lv0.
20 - 3600s 180s [Device Para
/Security
/Miscellaneous]
290 MCDGV4 DOK-HB-MCDGV4-2E
