Woodward HighPROTEC - Direct Commands of the IEC60870-5-103

Communication Protocols
Parameter Description Setting range Default Menu path
Timezone Selection whether the timestamps in IEC103
messages shall be given as UTC or local
time. (“Local time” always includes the
actual daylight saving settings.)
UTC,
Local Time
UTC [Device Para
/IEC 103]
Energy Pulse
Rate
The energy values are always transmitted
as counter values (i.e. as integer numbers).
This setting defines the unit: If “1” is set
then each counter increment is 1 kWh, if “2”
is set then each counter increment is 2
kWh,etc. The setting “0” has the effect that
no energy values are transmitted.
0 - 100 0 [Device Para
/IEC 103]
DFC-Compat. This setting is only required for certain
substation implementations. If there should
be communication problems related to the
Command Response Queue this setting
switches the device over to a different
behavior.
inactive,
active
inactive [Device Para
/IEC 103]
Optical rest
position
Optical rest position Light off,
Light on
Light on [Device Para
/IEC 103]
Ex activate test
mode
The signal assigned to this parameter
switches the IEC103 communication into
Test Mode.
1..n,
Assignment List
Sgen.Running [Service
/Test (Prot
inhibit)
/Scada
/IEC 103]
Ex activate
Block MD
The signal assigned to this parameter
activates the blocking of IEC103
transmission in monitor direction.
1..n,
Assignment List
-.- [Service
/Test (Prot
inhibit)
/Scada
/IEC 103]
Direct Commands of the IEC60870-5-103
Parameter Description Setting range Default Menu path
Activate test
mode
This Direct Control parameter switches the
IEC103 communication into Test Mode (or
back to nomal mode).
inactive,
active
inactive [Service
/Test (Prot
inhibit)
/Scada
/IEC 103]
359 MCDGV4 DOK-HB-MCDGV4-2E
