Switchgear/Breaker – Manager
After the single line diagram has been loaded, each individual switchgear has to be configured. The following table
shows the required configurations dependent on the type of switchgear.
To be configured at:
Type of switchgear
[Control\SG\Designation
of switchgear]
Circuit Breaker
(controlled)
Circuit Breaker
(supervised)
Switch Disconnector
(controlled)
Switch Disconnector
(supervised)
Ground Connector
(controlled)
Ground Connector
(supervised)
Disconnector
(controlled)
Disconnector
(supervised)
Assignment of position
indications
(Digital inputs)
x x x x x x x x
Assignment of commands
(Output relays)
x - x - x - x -
Setting of supervision
timers
x x x x x x x x
Interlockings x - x - x - x -
Trip Manager
(Assignment of trip commands)
x x - - - - - -
Optional: Synchronous
switching
x - - - - - - -
Optional: Ex ON/OFF Cmd x - x - x - x -
Optional: SGW x x x x x x x x
527 MCDGV4 DOK-HB-MCDGV4-2E
