Device Parameters
Parameter Description Setting range Default Menu path
Ack via »C« key Select which acknowledgeable elements can
be reset via pressing the »C« key.
Nothing,
Ack LEDs,
Ack LEDs,
relays,
Ack Everything
Ack LEDs [Device Para
/Acknowledge]
Remote Reset Enables or disables the option to
acknowledge from external/remote via
signals (assignments) and SCADA.
inactive,
active
active [Device Para
/Acknowledge]
Ack LED All acknowledgeable LEDs will be
acknowledged if the state of the assigned
signal becomes true.
Only available if: Remote Reset = active
1..n,
Assignment List
-.- [Device Para
/Acknowledge]
Ack BO All acknowledgeable binary output relays
will be acknowledged if the state of the
assigned signal becomes true.
Only available if: Remote Reset = active
1..n,
Assignment List
-.- [Device Para
/Acknowledge]
Ack Scada SCADA will be acknowledged if the state of
the assigned signal becomes true.
Only available if: Remote Reset = active
1..n,
Assignment List
-.- [Device Para
/Acknowledge]
Scaling Display of the measured values as primary,
secondary or per unit values
Per unit values,
Primary values,
Secondary
values
Per unit
values
[Device Para
/Measurem
Display
/General
Settings]
Lock Settings No parameters can be changed as long as
this input is true. The parameter settings
are locked.
1..n,
Assignment List
-.- [Field Para
/General
Settings]
