Measuring Values
Value Description Menu path
VL12 THD Measured value (calculated): V12 Total Harmonic
Distortion
[Operation
/Measured Values
/Voltage RMS]
VL23 THD Measured value (calculated): V23 Total Harmonic
Distortion
[Operation
/Measured Values
/Voltage RMS]
VL31 THD Measured value (calculated): V31 Total Harmonic
Distortion
[Operation
/Measured Values
/Voltage RMS]
VL1 THD Measured value (calculated): VL1 Total Harmonic
Distortion
[Operation
/Measured Values
/Voltage RMS]
VL2 THD Measured value (calculated): VL2 Total Harmonic
Distortion
[Operation
/Measured Values
/Voltage RMS]
VL3 THD Measured value (calculated): VL3 Total Harmonic
Distortion
[Operation
/Measured Values
/Voltage RMS]
VX meas H3 Third harmonic of measured neutral voltage used to
detect generator stator ground faults.
[Operation
/Measured Values
/Voltage ]
V/f Ratio Volts/Hertz in relation to nominal values. [Operation
/Measured Values
/Voltage RMS]
245 MCDGV4 DOK-HB-MCDGV4-2E
