Measuring Values
Value Description Menu path
phi V0 Measured value (calculated): Angle Zero Sequence
System
Reference phasor is required to calculate the angle.
[Operation
/Measured Values
/Voltage ]
phi V1 Measured value (calculated): Angle of Positive
Sequence System
Reference phasor is required to calculate the angle.
[Operation
/Measured Values
/Voltage ]
phi V2 Measured Value (calculated): Angle of Negative
Sequence System
Reference phasor is required to calculate the angle.
[Operation
/Measured Values
/Voltage ]
%(V2/V1) Measured value (calculated): V2/V1, phase sequence
will be taken into account automatically.
[Operation
/Measured Values
/Voltage ]
%VL12 THD Measured value (calculated): V12 Total Harmonic
Distortion / Ground wave
[Operation
/Measured Values
/Voltage RMS]
%VL23 THD Measured value (calculated): V23 Total Harmonic
Distortion / Ground wave
[Operation
/Measured Values
/Voltage RMS]
%VL31 THD Measured value (calculated): V31 Total Harmonic
Distortion / Ground wave
[Operation
/Measured Values
/Voltage RMS]
%VL1 THD Measured value (calculated): VL1 Total Harmonic
Distortion / Ground wave
[Operation
/Measured Values
/Voltage RMS]
%VL2 THD Measured value (calculated): VL2 Total Harmonic
Distortion / Ground wave
[Operation
/Measured Values
/Voltage RMS]
%VL3 THD Measured value (calculated): VL3 Total Harmonic
Distortion / Ground wave
[Operation
/Measured Values
/Voltage RMS]
