Measuring Values
Value Description Menu path
VX meas RMS Measured value (measured): VX measured (RMS) [Operation
/Measured Values
/Voltage RMS]
VG calc RMS Measured value (calculated): VG (RMS) [Operation
/Measured Values
/Voltage RMS]
phi VL12 Measured value (calculated): Angle of Phasor VL12
This phase is used as reference to calculate the
angles of other phases. Only if:VT con!=Phase to
Ground
[Operation
/Measured Values
/Voltage ]
phi VL23 Measured value (calculated): Angle of Phasor VL23
Reference phasor is required to calculate the angle.
[Operation
/Measured Values
/Voltage ]
phi VL31 Measured value (calculated): Angle of Phasor VL31
Reference phasor is required to calculate the angle.
[Operation
/Measured Values
/Voltage ]
phi VL1 Measured value (calculated): Angle of Phasor VL1
This phase is used as reference to calculate the
angles of other phases. Only if:VT con=Phase to
Ground
[Operation
/Measured Values
/Voltage ]
phi VL2 Measured value (calculated): Angle of Phasor VL2
Reference phasor is required to calculate the angle.
[Operation
/Measured Values
/Voltage ]
phi VL3 Measured value (calculated): Angle of Phasor VL3
Reference phasor is required to calculate the angle.
[Operation
/Measured Values
/Voltage ]
phi VX meas Measured value: Angle of Phasor VX meas
Reference phasor is required to calculate the angle.
[Operation
/Measured Values
/Voltage ]
phi VG calc Measured value (calculated): Angle of Phasor VG calc
Reference phasor is required to calculate the angle.
[Operation
/Measured Values
/Voltage ]
