Woodward HighPROTEC - Page 146

Input, Output and LED Settings
OR-5 X
BO Slot X6
Direct Commands of OR-5 X
Parameter Description Setting range Default Menu path
DISARMED This is the second step, after the
"DISARMED Ctrl" has been activated, that is
required to DISARM the relay outputs. This
will DISARM those output relays that are
currently not latched and that are not on
“hold” by a pending minimum hold time.
CAUTION! RELAYS DISARMED in order to
safely perform maintenance while
eliminating the risk of taking an entire
process off-line. (Note: Zone Interlocking
and Supervision Contact cannot be
disarmed). YOU MUST ENSURE that the
relays are ARMED AGAIN after maintenance.
Only available if: DISARMED Ctrl = active
inactive,
active
inactive [Service
/Test (Prot
inhibit)
/DISARMED
/BO Slot X6]
Force all Outs By means of this function the normal Output
Relay State can be overwritten (forced). The
relay can be set from normal operation
(relay works according to the assigned
signals) to "force energized" or "force de-
energized" state. Forcing all outputs relays
of an entire assembly group is superior to
forcing a single output relay.
Normal,
De-Energized,
Energized
Normal [Service
/Test (Prot
inhibit)
/Force OR
/BO Slot X6]
Force OR1 By means of this function the normal Output
Relay State can be overwritten (forced). The
relay can be set from normal operation
(relay works according to the assigned
signals) to "force energized" or "force de-
energized" state.
Normal,
De-Energized,
Energized
Normal [Service
/Test (Prot
inhibit)
/Force OR
/BO Slot X6]
Force OR2 By means of this function the normal Output
Relay State can be overwritten (forced). The
relay can be set from normal operation
(relay works according to the assigned
signals) to "force energized" or "force de-
energized" state.
Normal,
De-Energized,
Energized
Normal [Service
/Test (Prot
inhibit)
/Force OR
/BO Slot X6]
Force OR3 By means of this function the normal Output
Relay State can be overwritten (forced). The
relay can be set from normal operation
(relay works according to the assigned
signals) to "force energized" or "force de-
energized" state.
Normal,
De-Energized,
Energized
Normal [Service
/Test (Prot
inhibit)
/Force OR
/BO Slot X6]
146 MCDGV4 DOK-HB-MCDGV4-2E
