Woodward HighPROTEC - Page 22

IMPORTANT DEFINITIONS
Output Signal Description / Diagram
────────────────
➁
(Symbol)
name . Trip L1
Each trip of an active, trip authorized protection module will lead
to a general trip.
─────────❨16❩
─────────❨16a❩
─────────❨16b❩
name . Trip L2
Each trip of an active, trip authorized protection module will lead
to a general trip.
─────────❨17❩
─────────❨17a❩
─────────❨17b❩
name . Trip L3
Each trip of an active, trip authorized protection module will lead
to a general trip.
─────────❨18❩
─────────❨18a❩
─────────❨18b❩
name . TripCmd
Each trip of an active, trip authorized protection module will lead
to a general trip.
─────────❨19❩
─────────❨19a❩
─────────❨19b❩
─────────❨19c❩
name . TripCmd
Each trip of an active, trip authorized protection module will lead
to a general trip.
─────────❨19d❩
name . Trip L1
Each trip of an active, trip authorized protection module will lead
to a general trip.
─────────❨20❩
name . Trip L2
Each trip of an active, trip authorized protection module will lead
to a general trip.
─────────❨21❩
name . Trip L3
Each trip of an active, trip authorized protection module will lead
to a general trip.
─────────❨22❩
name . Trip
Each trip of an active, trip authorized protection module will lead
to a general trip.
─────────❨23❩
name . Alarm L1
Each phase selective alarm of a module (I, IG, V, VX depending
on the device type) will lead to a phase selective general alarm
(collective alarm).
─────────❨24❩
─────────❨24a❩
─────────❨24b❩
name . Alarm L2
Each phase selective alarm of a module (I, IG, V, VX depending
on the device type) will lead to a phase selective general alarm
(collective alarm).
─────────❨25❩
─────────❨25a❩
─────────❨25b❩
name . Alarm L3
Each phase selective alarm of a module (I, IG, V, VX depending
on the device type) will lead to a phase selective general alarm
(collective alarm).
─────────❨26❩
─────────❨26a❩
─────────❨26b❩
22 MCDGV4 DOK-HB-MCDGV4-2E
