System Alarms
Parameter Description Setting range Default Menu path
Threshold Threshold (to be entered as primary value) 1 -
40000000kVA
20000kVA [SysA
/Demand
/Power
Demand
/VA Demand]
t-Delay Tripping Delay 0 - 60min 0min [SysA
/Demand
/Power
Demand
/VA Demand]
Alarm Alarm inactive,
active
inactive [SysA
/Demand
/Current
Demand]
Threshold Threshold (to be entered as primary value) 10 - 500000A 500A [SysA
/Demand
/Current
Demand]
t-Delay Tripping Delay 0 - 60min 0min [SysA
/Demand
/Current
Demand]
Alarm Alarm inactive,
active
inactive [SysA
/THD
/I THD]
Threshold Threshold (to be entered as primary value) 1 - 500000A 500A [SysA
/THD
/I THD]
t-Delay Tripping Delay 0 - 3600s 0s [SysA
/THD
/I THD]
Alarm Alarm inactive,
active
inactive [SysA
/THD
/V THD]
Threshold Threshold (to be entered as primary value) 1 - 500000V 10000V [SysA
/THD
/V THD]
281 MCDGV4 DOK-HB-MCDGV4-2E
