Acknowledgments
Options for individual acknowledgments for latched signals:
Individual Acknowledgment
LEDs Binary Output Relays Pending
Trip Command
Via a signal from the
assignment list (e.g.:a
digital Input) a
single
... can
be acknowledged.
Single LED:
Where?
Within the configuration
menu of this single LED.
Binary Output Relay:
Where?
Within the configuration
menu of this single Binary
Output Relay.
Pending Trip Command.
Where?
Within the module
TripControl
As long as you are within the parameter setting mode, you cannot
acknowledge.
In case of a fault during parameter setting via the operating panel, you must
first leave the parameter mode by pressing either push-button »C« or »OK«
before you may access to menu »Acknowledgments« via push-button.
285 MCDGV4 DOK-HB-MCDGV4-2E
