Recorders
Direct Commands of the Fault Recorder
Parameter Description Setting range Default Menu path
Res all rec Reset all records inactive,
active
inactive [Operation
/Reset]
Global Protection Parameters of the Fault Recorder
Parameter Description Setting range Default Menu path
Record-Mode Recorder Mode (Set the behaviour of the
recorder)
Alarms and
Trips,
Trips only
Trips only [Device Para
/Recorders
/Fault rec]
t-meas-delay After the Trip, the measurement will be
delayed for this time.
0 - 60ms 0ms [Device Para
/Recorders
/Fault rec]
Fault Recorder Signals
Signal Description
Res rec Signal: Delete record
