Woodward HighPROTEC - Page 330

Communication Protocols
Parameter Description Setting range Default Menu path
Latched Config
Bin Inp24
Latched Configurable Binary Input inactive,
active
inactive [Device Para
/Modbus
/Configb
Registers
/States]
Config Bin
Inp25
Virtual Digital Input. This corresponds to a
virtual binary output of the protective
device.
1..n,
Assignment List
-.- [Device Para
/Modbus
/Configb
Registers
/States]
Latched Config
Bin Inp25
Latched Configurable Binary Input inactive,
active
inactive [Device Para
/Modbus
/Configb
Registers
/States]
Config Bin
Inp26
Virtual Digital Input. This corresponds to a
virtual binary output of the protective
device.
1..n,
Assignment List
-.- [Device Para
/Modbus
/Configb
Registers
/States]
Latched Config
Bin Inp26
Latched Configurable Binary Input inactive,
active
inactive [Device Para
/Modbus
/Configb
Registers
/States]
Config Bin
Inp27
Virtual Digital Input. This corresponds to a
virtual binary output of the protective
device.
1..n,
Assignment List
-.- [Device Para
/Modbus
/Configb
Registers
/States]
Latched Config
Bin Inp27
Latched Configurable Binary Input inactive,
active
inactive [Device Para
/Modbus
/Configb
Registers
/States]
Config Bin
Inp28
Virtual Digital Input. This corresponds to a
virtual binary output of the protective
device.
1..n,
Assignment List
-.- [Device Para
/Modbus
/Configb
Registers
/States]
330 MCDGV4 DOK-HB-MCDGV4-2E
