Communication Protocols
Parameter Description Setting range Default Menu path
Mapped Meas
14
Mapped Measured Values. They can be used
to provide measured values to the Modbus
Master.
1..n,
TrendRecList
-.- [Device Para
/Modbus
/Configb
Registers
/Measured
Values]
Mapped Meas
15
Mapped Measured Values. They can be used
to provide measured values to the Modbus
Master.
1..n,
TrendRecList
-.- [Device Para
/Modbus
/Configb
Registers
/Measured
Values]
Mapped Meas
16
Mapped Measured Values. They can be used
to provide measured values to the Modbus
Master.
1..n,
TrendRecList
-.- [Device Para
/Modbus
/Configb
Registers
/Measured
Values]
States of the Module Inputs of the MODBUS
®
Protocol
Name Description Assignment via
Config Bin Inp1-I State of the module input: Config Bin Inp [Device Para
/Modbus
/Configb Registers
/States]
Config Bin Inp2-I State of the module input: Config Bin Inp [Device Para
/Modbus
/Configb Registers
/States]
Config Bin Inp3-I State of the module input: Config Bin Inp [Device Para
/Modbus
/Configb Registers
/States]
Config Bin Inp4-I State of the module input: Config Bin Inp [Device Para
/Modbus
/Configb Registers
/States]
