Communication Protocols
IEC 61850 Module Values
Value Description Default Size Menu path
NoOfGooseRxAll Total number of received GOOSE
messages including messages for other
devices (subscribed and not subscribed
messages).
0 0 -
9999999999
[Operation
/Count and RevData
/IEC61850]
NoOfGooseRxSub
scribed
Total Number of subscribed GOOSE
messages including messages with
incorrect content.
0 0 -
9999999999
[Operation
/Count and RevData
/IEC61850]
NoOfGooseRxCor
rect
Total Number of subscribed and
correctly received GOOSE messages.
0 0 -
9999999999
[Operation
/Count and RevData
/IEC61850]
NoOfGooseRxNe
w
Number of subscribed and correctly
received GOOSE messages with new
content.
0 0 -
9999999999
[Operation
/Count and RevData
/IEC61850]
NoOfGooseTxAll Total Number of GOOSE messages that
have been published by this device.
0 0 -
9999999999
[Operation
/Count and RevData
/IEC61850]
NoOfGooseTxNe
w
Total Number of new GOOSE messages
(modified content) that have been
published by this device.
0 0 -
9999999999
[Operation
/Count and RevData
/IEC61850]
NoOfServerRequ
estsAll
Total number of MMS Server requests
including incorrect requests.
0 0 -
9999999999
[Operation
/Count and RevData
/IEC61850]
NoOfDataReadAll Total Number of values read from this
device including incorrect requests.
0 0 -
9999999999
[Operation
/Count and RevData
/IEC61850]
NoOfDataReadCo
rrect
Total Number of correctly read values
from this device.
0 0 -
9999999999
[Operation
/Count and RevData
/IEC61850]
NoOfDataWritten
All
Total Number of values written by this
device including incorrect ones.
0 0 -
9999999999
[Operation
/Count and RevData
/IEC61850]
375 MCDGV4 DOK-HB-MCDGV4-2E
