Time Synchronization
Device Planning Parameters of the IRIG-B00X
Parameter Description Options Default Menu path
Mode Mode do not use,
use
do not use [Device planning]
Direct Commands of the IRIG-B00X
Parameter Description Setting range Default Menu path
Res IRIG-B Cr Resetting of the Diagnosis Counters: IRIG-B inactive,
active
inactive [Operation
/Reset]
Global Protection Parameters of the IRIG-B00X
Parameter Description Setting range Default Menu path
Function Permanent activation or deactivation of
module/stage.
inactive,
active
inactive [Device Para
/Time
/TimeSync
/IRIG-B]
IRIG-B00X Determination of the Type: IRIG-B00X. IRIG-
B types differ in types of included “Coded
Expressions” (year, control-functions,
straight-binary-seconds).
IRIGB-000,
IRIGB-001,
IRIGB-002,
IRIGB-003,
IRIGB-004,
IRIGB-005,
IRIGB-006,
IRIGB-007
IRIGB-000 [Device Para
/Time
/TimeSync
/IRIG-B]
Signals of the IRIG-B00X (Output States)
Signal Description
IRIG-B active Signal: If there is no valid IRIG-B signal for 60 sec, IRIG-B is regarded as
inactive.
High-Low Invert Signal: The High and Low signals of the IRIG-B are inverted. This does NOT
mean that the wiring is faulty. If the wiring is faulty no IRIG-B signal will be
detected.
Control Signal1 Signal: IRIG-B Control Signal. The external IRIG-B generator can set these
signals. They can be used for further control procedures inside the device
(e.g. logic funtions).
