Parameters
Signals that can be used for PSS
Name Description
-.- No assignment
Prot.DFT Invalid DFT values of fundamental and harmonics (except VX) are not valid. They depend on
period time of frequency and measured channels 1-3 (VL1,VL2,VL3).
Prot.DFT Valid DFT values of fundamental and harmonics (except VX) are valid. They depend on
period time of frequency and measured channels 1-3 (VL1,VL2,VL3).
Prot.DFT Invalid (VX) DFT values of fundamental and harmonics of VX (only) are not valid.
Prot.DFT Valid (VX) DFT values of fundamental and harmonics of VX (only) are valid.
CTS.Alarm Signal: Alarm Current Transformer Measuring Circuit Supervision
LOP.Alarm Signal: Alarm Loss of Potential
DI Slot X1.DI 1 Signal: Digital Input
DI Slot X1.DI 2 Signal: Digital Input
DI Slot X1.DI 3 Signal: Digital Input
DI Slot X1.DI 4 Signal: Digital Input
DI Slot X1.DI 5 Signal: Digital Input
DI Slot X1.DI 6 Signal: Digital Input
DI Slot X1.DI 7 Signal: Digital Input
DI Slot X1.DI 8 Signal: Digital Input
DI Slot X5.DI 1 Signal: Digital Input
DI Slot X5.DI 2 Signal: Digital Input
DI Slot X5.DI 3 Signal: Digital Input
DI Slot X5.DI 4 Signal: Digital Input
DI Slot X5.DI 5 Signal: Digital Input
DI Slot X5.DI 6 Signal: Digital Input
DI Slot X5.DI 7 Signal: Digital Input
DI Slot X5.DI 8 Signal: Digital Input
DI Slot X6.DI 1 Signal: Digital Input
DI Slot X6.DI 2 Signal: Digital Input
DI Slot X6.DI 3 Signal: Digital Input
DI Slot X6.DI 4 Signal: Digital Input
DI Slot X6.DI 5 Signal: Digital Input
DI Slot X6.DI 6 Signal: Digital Input
DI Slot X6.DI 7 Signal: Digital Input
DI Slot X6.DI 8 Signal: Digital Input
Logics.LE1.Gate Out Signal: Output of the logic gate
Logics.LE1.Timer Out Signal: Timer Output
Logics.LE1.Out Signal: Latched Output (Q)
Logics.LE1.Out inverted Signal: Negated Latched Output (Q NOT)
Logics.LE2.Gate Out Signal: Output of the logic gate
Logics.LE2.Timer Out Signal: Timer Output
466 MCDGV4 DOK-HB-MCDGV4-2E
