Switchgear/Breaker – Manager
Switching Authority
For the Switching Authority [Control\General Settings], the following general settings are possible:
NONE: No control function;
LOCAL: Control only via push buttons at the panel;
REMOTE: Control only via SCADA, digital inputs, or internal signals; and
LOCAL&REMOTE: Control via push buttons, SCADA, digital inputs, or internal signals.
538 MCDGV4 DOK-HB-MCDGV4-2E
Aux ON-I
Aux OFF-I
Ready-I
Sys-in-Sync-I
SG
OFF Cmd
ON Cmd
TripCmd
Prot ON
HMI
Autoreclosure CLOSE
Command
Scada
Ready to Close
synchro check
CBCloseInitiate-I
Condition for Generator2System
Signal Ready to Close
Sync ON request
*
*
*= * Availability dependent on device type
**=* Availability dependent on device type
