Switchgear/Breaker – Manager
Direct commands of the Switching Authority
Parameter Description Setting range Default Menu path
Switching
Authority
Switching Authority None,
Local,
Remote,
Local and
Remote
Local [Control
/General
Settings]
NonInterl DC for Non-Interlocking inactive,
active
inactive [Control
/General
Settings]
Signals of the Switching Authority
Signal Description
Local Switching Authority: Local
Remote Switching Authority: Remote
NonInterl Non-Interlocking is active
SG Indeterm Minimum one Switchgear is moving (Position cannot be determined).
SG Disturb Minimum one Switchgear is disturbed.
Counters of the Command Execution Supervision
Parameter Description
CES SAuthority Command Execution Supervision: Number of rejected Commands because
of missing switching authority.
CES DoubleOperating Command Execution Supervision: Number of rejected Commands because a
second switch command is in conflict with a pending one.
CES No. of rej. Com Command Execution Supervision: Number of rejected Commands because
Locked by ParaSystem
