Switchgear/Breaker – Manager
Value Description Default Size Menu path
Sum trip IL1 Summation of the tripping currents
phase
0.00A 0.00 -
1000.00A
[Operation
/Count and RevData
/Control
/SG[1]]
Sum trip IL2 Summation of the tripping currents
phase
0.00A 0.00 -
1000.00A
[Operation
/Count and RevData
/Control
/SG[1]]
Sum trip IL3 Summation of the tripping currents
phase
0.00A 0.00 -
1000.00A
[Operation
/Count and RevData
/Control
/SG[1]]
Isum Intr per
hour
Sum per hour of interrupting currents. 0.00kA 0.00 -
1000.00kA
[Operation
/Count and RevData
/Control
/SG[1]]
CB OPEN
capacity
Used capacity of the circuit breaker.
(100% means that the circuit breaker
has to be maintained.)
0.0% 0.0 - 100.0% [Operation
/Count and RevData
/Control
/SG[1]]
Direct Commands of the Breaker Wear Module
Parameter Description Setting range Default Menu path
Res TripCmd Cr Resetting of the Counter: total number of
trip commands
inactive,
active
inactive [Operation
/Reset]
Res Sum trip Reset summation of the tripping currents inactive,
active
inactive [Operation
/Reset]
Res Isum Intr
per hour
Reset of the Sum per hour of interrupting
currents.
inactive,
active
inactive [Operation
/Reset]
