Switchgear/Breaker – Manager
Parameter Description Setting range Default Menu path
Removed The withdrawable circuit breaker is
Removed
Dependency
1..n, DI-
LogicList
-.- [Control
/SG
/SG[4]
/Pos Indicatrs
Wirng]
Interl ON1 Interlocking of the ON command 1..n,
Assignment List
SG[1].Pos ON [Control
/SG
/SG[4]
/Interlockings]
Interl ON2 Interlocking of the ON command 1..n,
Assignment List
SG[6].Pos ON [Control
/SG
/SG[4]
/Interlockings]
Interl ON3 Interlocking of the ON command 1..n,
Assignment List
-.- [Control
/SG
/SG[4]
/Interlockings]
Interl OFF1 Interlocking of the OFF command 1..n,
Assignment List
SG[1].Pos ON [Control
/SG
/SG[4]
/Interlockings]
Interl OFF2 Interlocking of the OFF command 1..n,
Assignment List
-.- [Control
/SG
/SG[4]
/Interlockings]
Interl OFF3 Interlocking of the OFF command 1..n,
Assignment List
-.- [Control
/SG
/SG[4]
/Interlockings]
SCmd ON Switching ON Command, e.g. the state of
the Logics or the state of the digital input
1..n, DI-
LogicList
-.- [Control
/SG
/SG[4]
/Ex ON/OFF
Cmd]
SCmd OFF Switching OFF Command, e.g. the state of
the Logics or the state of the digital input
1..n, DI-
LogicList
-.- [Control
/SG
/SG[4]
/Ex ON/OFF
Cmd]
