Switchgear/Breaker – Manager
Name Description Assignment via
Removed-I State of the module input: The withdrawable circuit
breaker is Removed
[Control
/SG
/SG[2]
/Pos Indicatrs Wirng]
Ack TripCmd-I State of the module input: Acknowledgement Signal
(only for automatic acknowledgement) Module input
signal
[Control
/SG
/SG[2]
/Trip Manager]
Interl ON1-I State of the module input: Interlocking of the ON
command
[Control
/SG
/SG[2]
/Interlockings]
Interl ON2-I State of the module input: Interlocking of the ON
command
[Control
/SG
/SG[2]
/Interlockings]
Interl ON3-I State of the module input: Interlocking of the ON
command
[Control
/SG
/SG[2]
/Interlockings]
Interl OFF1-I State of the module input: Interlocking of the OFF
command
[Control
/SG
/SG[2]
/Interlockings]
Interl OFF2-I State of the module input: Interlocking of the OFF
command
[Control
/SG
/SG[2]
/Interlockings]
Interl OFF3-I State of the module input: Interlocking of the OFF
command
[Control
/SG
/SG[2]
/Interlockings]
SCmd ON-I State of the module input: Switching ON Command,
e.g. the state of the Logics or the state of the digital
input
[Control
/SG
/SG[2]
/Ex ON/OFF Cmd]
