Switchgear/Breaker – Manager
Signal Description
TripCmd Signal: Trip Command
Ack TripCmd Signal: Acknowledge Trip Command
ON incl Prot ON Signal: The ON Command includes the ON Command issued by the
Protection module.
OFF incl TripCmd Signal: The OFF Command includes the OFF Command issued by the
Protection module.
Position Ind manipul Signal: Position Indicators faked
SGwear Slow SG Signal: Alarm, the circuit breaker (load-break switch) becomes slower
Res SGwear Sl SG Signal: Resetting the slow Switchgear Alarm
ON Cmd Signal: ON Command issued to the switchgear. Depending on the setting
the signal may include the ON command of the Prot module.
OFF Cmd Signal: OFF Command issued to the switchgear. Depending on the setting
the signal may include the OFF command of the Prot module.
ON Cmd manual Signal: ON Cmd manual
OFF Cmd manual Signal: OFF Cmd manual
Sync ON request Signal: Synchronous ON request
624 MCDGV4 DOK-HB-MCDGV4-2E
