Installation and Connection
AN I02 X - Analog Inputs and Outputs
There are 2 Analog Input and 2 Analog Output channels that are configurable to either 0-20 mA, 4-20 mA, or 0-
10 V. Each of the channels can be independently programmed to either of these three input/output modes.
For details on the Analog Inputs/Outputs, please refer to the Technical Data.
Wiring
- Shielded cable is recommended
HF-Shield
– The terminals of the HF shield should be used, when connecting the shield to earth on both sides of the cable is
not possible. On one side of the cable the shield has to be directly connected to earth.
Ensure the correct tightening torques.
For details on the Analog Inputs or Outputs please refer to the Technical Data.
63 MCDGV4 DOK-HB-MCDGV4-2E
