Protective Elements
The recommended settings for the CT saturation monitor are (for usual applications):
• »CT Satur Monit« = “active”
• »CT Satur Sensitvn « = 120 % (Sensitiveness of the Current Transformer Satusation Supervision. The
higher the value, the lower the sensitiveness.)
647 MCDGV4 DOK-HB-MCDGV4-2E
Idmax
Id
Pure sinusoidal waveform
t
Derivative
Derivative
real
