Protective Elements
Value Description Menu path
Id L2 H4 Measured value (calculated): Differential Current
Phase L2 Harmonic:4
[Operation
/Measured Values
/Id]
Id L3 H4 Measured value (calculated): Differential Current
Phase L3 Harmonic:4
[Operation
/Measured Values
/Id]
Id L1 H5 Measured value (calculated): Differential Current
Phase L1 Harmonic:5
[Operation
/Measured Values
/Id]
Id L2 H5 Measured value (calculated): Differential Current
Phase L2 Harmonic:5
[Operation
/Measured Values
/Id]
Id L3 H5 Measured value (calculated): Differential Current
Phase L3 Harmonic:5
[Operation
/Measured Values
/Id]
Phase Current Differential Protection Module Statistics
Value Description Menu path
Id L1H2max Maximum Value Id L1H2 [Operation
/Statistics
/Max
/Id]
Id L2H2max Maximum Value Id L2H2 [Operation
/Statistics
/Max
/Id]
Id L3H2max Maximum Value Id L3H2 [Operation
/Statistics
/Max
/Id]
Id L1H4max Maximum Value Id L1H4 [Operation
/Statistics
/Max
/Id]
