Protective Elements
Signals of the Unrestrained High-set Differential Current Protection Signals (Output States)
Signal Description
active Signal: active
ExBlo Signal: External Blocking
Blo TripCmd Signal: Trip Command blocked
ExBlo TripCmd Signal: External Blocking of the Trip Command
Alarm L1 Signal: Alarm System Phase L1
Alarm L2 Signal: Alarm System Phase L2
Alarm L3 Signal: Alarm System L3
Alarm Signal: Alarm
Trip L1 Signal: Trip System Phase L1
Trip L2 Signal: Trip System Phase L2
Trip L3 Signal: Trip System Phase L3
Trip Signal: Trip
TripCmd Signal: Trip Command
