Protective Elements
Parameter Description Setting range Default Menu path
Tmin Minimum operating time for inverse
characteristics which prevent false trips for
faults that would be cleared normally by
system protection.
Only available if: Characteristic = INV
0.00 - 50.00s 0.25s [Protection
Para
/<1..4>
/I-Prot
/I2>G[1]]
46G - Definite Time Element Element Input States
Name Description Assignment via
ExBlo1-I Module input state: External blocking1 [Protection Para
/Global Prot Para
/I-Prot
/I2>G[1]]
ExBlo2-I Module input state: External blocking2 [Protection Para
/Global Prot Para
/I-Prot
/I2>G[1]]
ExBlo TripCmd-I Module input state: External Blocking of the Trip
Command
[Protection Para
/Global Prot Para
/I-Prot
/I2>G[1]]
46G - Definite Time Element Element Signals (Output States)
Signal Description
active Signal: active
ExBlo Signal: External Blocking
Blo TripCmd Signal: Trip Command blocked
ExBlo TripCmd Signal: External Blocking of the Trip Command
Alarm Signal: Alarm Negative Sequence
Trip Signal: Trip
TripCmd Signal: Trip Command
