Woodward HighPROTEC - Page 794

Protective Elements
Device Planning Parameters of the Inadvertent Energization
Parameter Description Options Default Menu path
Mode Mode do not use,
use
do not use [Device planning]
Global Protection Parameters of the Inadvertent Energization
Parameter Description Setting range Default Menu path
ExBlo1 External blocking of the module, if blocking
is activated (allowed) within a parameter set
and if the state of the assigned signal is
true.
1..n,
Assignment List
-.- [Protection
Para
/Global Prot
Para
/InEn]
ExBlo2 External blocking of the module, if blocking
is activated (allowed) within a parameter set
and if the state of the assigned signal is
true.
1..n,
Assignment List
-.- [Protection
Para
/Global Prot
Para
/InEn]
ExBlo TripCmd External blocking of the Trip Command of
the module/the stage, if blocking is
activated (allowed) within a parameter set
and if the state of the assigned signal is
true.
1..n,
Assignment List
-.- [Protection
Para
/Global Prot
Para
/InEn]
Assigned SG Assigned Switchgear -.-,
SG[1].Pos,
SG[2].Pos,
SG[3].Pos,
SG[4].Pos,
SG[5].Pos,
SG[6].Pos
SG[1].Pos [Protection
Para
/Global Prot
Para
/InEn]
794 MCDGV4 DOK-HB-MCDGV4-2E
