Protective Elements
Parameter Description Setting range Default Menu path
Pickup Delay The pickup time delay is the time for the
undervoltage unit to operate to arm the
protection.
0.00 - 300.00s 5.00s [Protection
Para
/<1..4>
/InEn]
Dropout Delay The dropout time delay is the time for the
unit to operate to disarm the protection
when the voltage is increased above the
pickup value or the generator is brought on-
line.
0.00 - 300.00s 0.25s [Protection
Para
/<1..4>
/InEn]
Meas Circuit
Superv
Activates the use of the measuring circuit
supervision. In this case the module will be
blocked if a measuring circuit supervision
module (e.g. LOP, VTS) signals a disturbed
measuring circuit (e.g. caused by a fuse
failure).
inactive,
active
inactive [Protection
Para
/<1..4>
/InEn]
Inputs of the Inadvertent Energization
Name Description Assignment via
ExBlo1-I Module input state: External blocking1 [Protection Para
/Global Prot Para
/InEn]
ExBlo2-I Module input state: External blocking2 [Protection Para
/Global Prot Para
/InEn]
ExBlo TripCmd-I Module input state: External Blocking of the Trip
Command
[Protection Para
/Global Prot Para
/InEn]
Signals (Output States) of the Inadvertent Energization
Signal Description
active Signal: active
ExBlo Signal: External Blocking
Blo TripCmd Signal: Trip Command blocked
ExBlo TripCmd Signal: External Blocking of the Trip Command
Alarm Signal: Inadvertent Energization
Trip Signal: Trip
TripCmd Signal: Trip Command
