Protective Elements
Parameter Description Setting range Default Menu path
AdaptSet 1 Assignment Adaptive Parameter 1 AdaptSet -.- [Protection
Para
/Global Prot
Para
/Z
/Z[1]]
AdaptSet 2 Assignment Adaptive Parameter 2 AdaptSet -.- [Protection
Para
/Global Prot
Para
/Z
/Z[1]]
Setting Group Parameters of the Phase Distance Protection Module
The actually available value range for all impedance settings is dependent on
the Field Parameter setting »CT sec« . This dependency is not properly
reflected in the parameter table below.
• For »CT sec« = 1 A the min. value from the “Setting Range” table row
has to be multiplied by 5.
• For »CT sec« = 5 A the max. value from the “Setting Range” table row
has to be divided by 5.
Parameter Description Setting range Default Menu path
Function Permanent activation or deactivation of
module/stage.
inactive,
active
inactive [Protection
Para
/<1..4>
/Z
/Z[1]
/General
Settings]
ExBlo Fc Activate (allow) or inactivate (disallow)
blocking of the module/stage. This
parameter is only effective if a signal is
assigned to the corresponding global
protection parameter. If the signal becomes
true, those modules/stages are blocked that
are parameterized "ExBlo Fc=active".
inactive,
active
inactive [Protection
Para
/<1..4>
/Z
/Z[1]
/General
Settings]
