Protective Elements
Device Planning Parameters of the Cold Load Pickup Module
Parameter Description Options Default Menu path
Mode Mode do not use,
use
do not use [Device planning]
Global Protection Parameter of the Cold Load Pickup Module
Parameter Description Setting range Default Menu path
Mode Mode CB Pos,
I<,
CB Pos Or I<,
CB Pos And I<
CB Pos [Protection
Para
/Global Prot
Para
/CLPU]
ExBlo1 External blocking of the module, if blocking
is activated (allowed) within a parameter set
and if the state of the assigned signal is
true.
1..n,
Assignment List
-.- [Protection
Para
/Global Prot
Para
/CLPU]
ExBlo2 External blocking of the module, if blocking
is activated (allowed) within a parameter set
and if the state of the assigned signal is
true.
1..n,
Assignment List
-.- [Protection
Para
/Global Prot
Para
/CLPU]
Ex rev Interl External blocking of the module by external
reverse interlocking, if blocking is activated
(allowed) within a parameter set and if the
state of the assigned signal is true.
1..n,
Assignment List
-.- [Protection
Para
/Global Prot
Para
/CLPU]
CB Pos Detect Criterion by which the Circuit Breaker Switch
Position is to be detected.
Only available if: CLPU.Mode = I<
-.-,
SG[1].Pos,
SG[2].Pos,
SG[3].Pos,
SG[4].Pos,
SG[5].Pos,
SG[6].Pos
SG[1].Pos [Protection
Para
/Global Prot
Para
/CLPU]
