Protective Elements
States of the Inputs of the Cold Load Pickup Module
Name Description Assignment via
ExBlo1-I Module input state: External blocking [Protection Para
/Global Prot Para
/CLPU]
ExBlo2-I Module input state: External blocking [Protection Para
/Global Prot Para
/CLPU]
Ex rev Interl-I Module input state: External reverse interlocking [Protection Para
/Global Prot Para
/CLPU]
Signals of the Cold Load Pickup Module (States of the Outputs)
Signal Description
active Signal: active
ExBlo Signal: External Blocking
Ex rev Interl Signal: External reverse Interlocking
enabled Signal: Cold Load enabled
detected Signal: Cold Load detected
I< Signal: No Load Current.
Load Inrush Signal: Load Inrush
Settle Time Signal: Settle Time
876 MCDGV4 DOK-HB-MCDGV4-2E
