Protective Elements
Voltage Protection Module Input States
Name Description Assignment via
ExBlo1-I Module input state: External blocking1 [Protection Para
/Global Prot Para
/V-Prot
/V[1]]
ExBlo2-I Module input state: External blocking2 [Protection Para
/Global Prot Para
/V-Prot
/V[1]]
ExBlo TripCmd-I Module input state: External Blocking of the Trip
Command
[Protection Para
/Global Prot Para
/V-Prot
/V[1]]
Voltage Protection Module Signals (Output States)
Signal Description
active Signal: active
ExBlo Signal: External Blocking
Blo TripCmd Signal: Trip Command blocked
ExBlo TripCmd Signal: External Blocking of the Trip Command
Alarm L1 Signal: Alarm L1
Alarm L2 Signal: Alarm L2
Alarm L3 Signal: Alarm L3
Alarm Signal: Alarm voltage stage
Trip L1 Signal: General Trip Phase L1
Trip L2 Signal: General Trip Phase L2
Trip L3 Signal: General Trip Phase L3
Trip Signal: Trip
TripCmd Signal: Trip Command
Imin release active Signal that the Imin release (minimum current) check is enabled and does
not block the undervoltage detection at the moment.
