Protective Elements
Device Planning Parameters of the Residual Voltage Supervision Module
Parameter Description Options Default Menu path
Mode Mode do not use,
V>,
V<
do not use [Device planning]
Global Protection Parameters of the Residual Voltage Supervision Module
Parameter Description Setting range Default Menu path
ExBlo1 External blocking of the module, if blocking
is activated (allowed) within a parameter set
and if the state of the assigned signal is
true.
1..n,
Assignment List
-.- [Protection
Para
/Global Prot
Para
/V-Prot
/VG[1]]
ExBlo2 External blocking of the module, if blocking
is activated (allowed) within a parameter set
and if the state of the assigned signal is
true.
1..n,
Assignment List
-.- [Protection
Para
/Global Prot
Para
/V-Prot
/VG[1]]
ExBlo TripCmd External blocking of the Trip Command of
the module/the stage, if blocking is
activated (allowed) within a parameter set
and if the state of the assigned signal is
true.
1..n,
Assignment List
-.- [Protection
Para
/Global Prot
Para
/V-Prot
/VG[1]]
