Protective Elements
Values of the Syncrocheck
Value Description Default Size Menu path
Slip Freq Slip frequency 0Hz 0 - 70.000Hz [Operation
/Measured Values
/Synchronism]
Volt Diff Voltage difference between bus and
line.
0V 0 -
500000.0V
[Operation
/Measured Values
/Synchronism]
Angle Diff Angle difference between bus and line
voltages.
0° -360.0 -
360.0°
[Operation
/Measured Values
/Synchronism]
f Bus Bus frequency 0Hz 0 - 70.000Hz [Operation
/Measured Values
/Synchronism]
f Line Line frequency 0Hz 0 - 70.000Hz [Operation
/Measured Values
/Synchronism]
V Bus Bus Voltage 0V 0 -
500000.0V
[Operation
/Measured Values
/Synchronism]
V Line Line Voltage 0V 0 -
500000.0V
[Operation
/Measured Values
/Synchronism]
Angle Bus Bus Angle (Reference) 0° 0 - 360° [Operation
/Measured Values
/Synchronism]
Angle Line Line Angle 0° 0 - 360° [Operation
/Measured Values
/Synchronism]
Signals that Trigger a Synchrocheck
Name Description
-.- No assignment
SG[1].Sync ON request Signal: Synchronous ON request
SG[2].Sync ON request Signal: Synchronous ON request
SG[3].Sync ON request Signal: Synchronous ON request
SG[4].Sync ON request Signal: Synchronous ON request
SG[5].Sync ON request Signal: Synchronous ON request
