Product Overview
Xerox 6204 Wide Format Solution
User Guide
2-47
3. Remove the shaft and the partial roll or core from the machine.
4. Pinch the lever at the end of the shaft, and remove the shaft from the core of the roll media.
Note
Pinching the lever releases the spring tension roll media lock, making it possible for you can
remove the shaft from the core.
5. Pinch the lever at the end of the shaft, and insert the shaft into the new roll media. Be sure the roll
ends align with the media size guide.
To Next Page
