Product Overview
Xerox 6204 Wide Format Solution
User Guide
2-48
6. Adjust the roll media’s orientation, and place the shaft on the shaft guide.
7. Rotate the roll media until the lead edge is gripped in the roller.
The roll media will automatically load, and then stop.
Note
If the roll media cannot be loaded correctly because its lead edge is damaged, trim the lead edge
before setting it in place.
WARNING: Do not open the Roll 1 or the Roll 2 cutter cover unless you are specifically directed to
do so.
8. Press the cutter button to cut the lead edge of roll media.
The lead edge of the roll media is cut.
Note
Pressing the cutter button one time cuts about 8.3 inches (210 mm) of media from the lead edge
of the roll. When the cutter button is held down, the roll media feeds continuously until the cutter
button is released. The roll media is cut when the cutter button is released.
