Phaser 3140/3155/3160 Printer Service Manual I – 1
Index
A
abbreviations, A-2
AC
input connection
, 1-6
requirements, 1-13
troubleshooting, 4-12
altitude adjustment, 6-2
B
background contamination, 5-14
banding, 5-22
black lines, 5-21
black prints, 5-11
blank prints, 5-28
button
definitions
, 1-7
location, 1-7
C
clearances, 1-15
Clutch Assembly
part number
, 9-17
clutch assembly
removal
, 8-37
consumable, 1-10
Print Cartridge, 1-10
Control Panel
buttons
, 1-7
description, 1-7
Error LED, 1-8
Online LED, 1-8
part number, 9-7
removal, 8-51
Controller Board, 2-11
3140 wiring, 10-15
3155 wiring, 10-19
3160 wiring, 10-23
connector definitions, 2-11
designators, 10-2
operation, 2-11
part number, 9-5
removal, 8-51
CRUM, 2-8
curl, 5-31
D
dimensions, 1-15
Drive Assembly, 2-6
operation, 2-6
part number
3140
, 9-21
3155/3160, 9-23
removal, 8-35
E
electrostatic discharge, 0-xii
Error LED
color codes
, 1-8
Ethernet
port location
, 1-6
Exit Actuator
Spring
part number
, 9-27
Exit Sensor, 2-17
Exit Sensor Actuator
location
, 2-17
F
Fan, 2-17
part number, 9-16
removal, 8-58
fasteners, 8-5
precautions, 8-5
Feed Actuator
part number
, 9-17
removal, 8-40
Spring
part number
, 9-17
