Xerox Phaser 3160B Service Manual

I – 2 Phaser 3140/3155/3160 Printer Service Manual
Feed Pad Assembly, 2-4
Feed Roller
operation
, 2-5
part number, 9-17
removal, 8-38
Feed Sensor, 2-16
Firmware update, 7-5
fonts
supported
, 1-3
Front Cover
interlock switch
, 2-17
part number, 9-5
removal, 8-23
Fuser, 2-9
error recovery, 2-19
Exit Sensor, 2-17
ghosting image, 5-18
Heat Roller, 2-9
image defects, 5-9
jam, 3-21
life count, 1-9
location, 1-9
operation, 2-9
overheat protection, 2-10
part number, 9-5
Pressure Roller, 2-10
removal, 8-11
thermistor, 2-9
thermostat, 2-9
Fuser Lamp
part number
, 9-27
removal, 8-15
H
Heat Roller, 2-9
operation, 2-9, 2-19
part number, 9-27
removal, 8-17
I
image area, 5-32
interlock
Front Cover
, 2-17
functions, 2-10
L
Laser Unit, 2-7
3140 wiring, 10-16
3155 wiring, 10-20
3160 wiring, 10-24
cleaning, 7-4
errors, 2-20
HSYNC, 2-7
operation, 2-7, 2-20
part number, 9-18
removal, 8-30
LED
status/errors
, 3-14, 3-15, 3-23, 3-24
Left Cover
part number
, 9-9
Left Side Cover
removal
, 8-27
light prints, 5-10
M
maintenance items, 1-9
Manual Feed Actuator
assembly, part number
, 9-17
part number, 9-17
removal, 8-44
Spring
part number
, 9-17
Manual Feed Solenoid, 2-17
removal, 8-59
Manual Feeder, 2-4
supported media, 1-2
Manual Solenoid
part number
, 9-16
margins, 1-14
media
supported types
, 1-16
transport path, 2-3
memory
specifications
, 1-12, 2-12
N
noise, 5-31
Non-Xerox Print Cartridge, 1-10
O
Online LED
color codes
, 1-8
OPC drum, 2-7
ghosting image, 5-15
image defects, 5-9
Out Bin Full Sensor, 2-17
part number, 9-17
removal, 8-63
Output Tray
capacity
, 1-2
