3 Network Setup
Xerox Phaser 3200MFP 3-3
Configuring TCP/IP
Your machine can be set up with a variety of TCP/IP network information, such
as an IP address, a subnet mask, and a gateway. There are several ways in
which your machine can be assigned a TCP/IP address, depending on your
network.
• Dynamic addressing via BOOTP/DHCP (default): A TCP/IP address is
assigned automatically by the server.
• Static addressing: A TCP/IP address is assigned manually by the system
administrator.
NOTE: Before configuring TCP/IP, you need to set the network protocol to
TCP/IP.
Dynamic addressing (BOOTP/DHCP)
To have a TCP/IP address assigned automatically by the server, take the
following steps:
1. Press Menu until Network Setup appears on the top line of the display.
2. Press the scroll button ( or ) until "Config Network" appears and press
Enter.
3. Press Enter when "TCP/IP" appears.
4. Press the scroll button ( or ) until "DHCP" or "BOOTP" appears and
press Enter.
5. Press Stop/Clear to return to Standby mode.
Static addressing
To enter a TCP/IP address from your machine’s control panel, take the
following steps:
1. Press Menu until "Network Setup" appears on the top line of the display.
2. Press the scroll button ( or ) until "Config Network" appears and press
Enter.
3. Press Enter when "TCP/IP" appears.
4. Press Enter when "Manual" appears.
5. Press Enter when "IP Address" appears.
6. Enter a byte between 0 and 255 using the number keypad and press the
scroll button ( or ) to move between bytes.
7. Repeat this to complete the address from the 1st byte to the 4th byte.
8. When you have finished, press Enter.
