Xerox WorkCentre 4265 Service Manual

January 2016
3-24
WorkCentre WorkCentre 4150/4250/4260WorkCentre 4150/4250/42604150/
IQS 2, IQS 3
Image Quality
IQS 2 Skew
Documents
Test pattern: 82P524 (8.5 x 14), 82E2020 (8.5 x 11) or 82E2010 (A4).
NOTE: Test pattern 82P524 is a mylar document and should be copied from the document
glass only.
Specification
Refer to Table 1.
IQS 3 Registration
Documents
Test pattern: 82P524 (8.5 x 14), 82E2020 (8.5 x 11) or 82E2010 (A4).
NOTE: Test pattern 82P524 is a mylar document and should be copied from the document
glass only.
Specifications
Refer to Table 1.
Corrective Action
Go to the IQ19 Poor Registration RAP.
Table 1 Skew specifications
Skew Specification
Print Skew Max: +/-2.5mm (7/64 inch) per 250mm (10 inches) (+/-1%)
Table 1 Registration measurement
Registration Specification
Lead edge 4mm (5/32 inches) +/- 3mm (1/8 inches)
Top edge 4mm (5/32 inches) +/- 3mm (1/8 inches)

Xerox WorkCentre 4265 Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax, Email
Print Resolution (Max)	Up to 1200 x 1200 dpi
Memory (Standard)	2 GB
Memory (Maximum)	2 GB
Connectivity	10/100/1000Base-T Ethernet, USB 2.0
Paper Output	250 sheets
Scan Resolution (Optical)	Up to 600 x 600 dpi
Fax Speed	33.6 Kbps
Media Sizes Supported	Legal, Letter
Mobile Printing	Apple AirPrint
Duplex Printing	Automatic
Display	7-inch color touchscreen
