January 2016
6-63
WorkCentre 4150/4250/4260WorkCentre 4150/4250/4260WorkCentre Work-
dC132, dC135
General Procedures and Information
• All Fax Directories
• Fax Job NVM
• Fax Configuration NVM
• Fax SA/KO Settings NVM
5. Switch off the machine, then switch on the machine.
Procedure (4265)
1. Enter Diagnostics, GP 1.
2. Select Fax & NW Diagnostics.
3. Select dC 132 NVM Initialization - Fax.
4. Select Initialize All NVM - Fax.
5. Switch off the machine, then switch on the machine.
dC135 High Frequency Service Items (4265)
Purpose
The purpose is to provide the CSE with the operational status of an HFSI item, how many
times that item has been used, and the Maximum Life expected out of that item.
Procedure
1. Enter diagnostics, GP 1.
2. Select Service Information.
3. Select dC 135 HFSI.
4. The dC 135 HFSI screen is displayed. It contains the following fields for all the HFSI items
on the machine:
• Item
•Status
•Unit
•Actual
• Max Life
5. When a particular HFSI item is selected, the item can be reset, edited (for Threshold and
Maximum Life) or closed (Table 1).
Table 2 Fax NVM
Fax file type Category Reformat
All Fax
Directories
Fax
Job
NVM
Fax
Configuration
NVM
Fax SA/KO
Settings
NVM
Dial Directories Y Y
Group Directories Y Y
Junk Directories Y Y
Logo Directories Y Y
Mailbox Directories Y Y
Poll Directories Y Y
Job Sets Y Y
Jobs Y Y
Image Y Y
Bitmaps Y Y
Job ID Y Y
Mailbox Y Y
Alarm Y Y
Fax Protocol Trace Y Y
Protocol Records Y Y
Container Versions Y
FAX NVM Configuration Y
Fax NVM SA/KO Settings Y
Table 1 dC 135 HFSI Items
Item Max Life
DADF Roller Life Page 150K
DADF Rubber Pad Life Page 100K
Tray 1 Pickup Roll Life Page 250K
Tray 2 Pickup Roll Life Page 250K
Tray 3 Pickup Roll Life Page 250K
Retard Roll Life Page 250K
Transfer Roll Life Page 120K
Fuser Unit Roll Life Page 250K
Bypass Rubber Pad Life Page 50K
To Next Page
