REP 7.6
Repairs and Adjustments
12. As necessary, remove the tray feed sensor, HCF door sensor or transport roll gear, Figure
3.
Figure 3 Sensors and gear
Tray feed sensor.
SCF door sensor.
Transport roll gear.
