Xerox WorkCentre 4265 Service Manual

January 2016
4-128
WorkCentre 4150/4250/4260WorkCentre WorkCentre 4150/4250/42604150/
REP 8.1
Repairs and Adjustments
5. Remove the Side Cover Assembly (Figure 3).
Figure 3 Removing the Side Cover Assembly
Replacement
Replacement is the reverse of the removal procedure.
1
Disengage the front and
rear dampers by sliding
them upwards and out of
the Damper Bracket.
2
Disengage the front and
rear hinges by pulling
upwards.
3
Remove the side cover assembly.

Xerox WorkCentre 4265 Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax, Email
Print Resolution (Max)	Up to 1200 x 1200 dpi
Memory (Standard)	2 GB
Memory (Maximum)	2 GB
Connectivity	10/100/1000Base-T Ethernet, USB 2.0
Paper Output	250 sheets
Scan Resolution (Optical)	Up to 600 x 600 dpi
Fax Speed	33.6 Kbps
Media Sizes Supported	Legal, Letter
Mobile Printing	Apple AirPrint
Duplex Printing	Automatic
Display	7-inch color touchscreen
