Xerox WorkCentre 4265 Service Manual

January 2016
4-132
WorkCentre 4150/4250/4260WorkCentre WorkCentre 4150/4250/42604150/
REP 8.2
Repairs and Adjustments
18. Remove the rear registration idler roll bearing, Figure 9.
Figure 9 Rear Bearing Removal
19. Release the front the and rear tension springs, Figure 10.
Figure 10 Tension Springs
1
Remove the E-clip,
then the bearing.
2
Remove the ground
clip.
1
Carefully release the
front tension spring.
2
Carefully release the
rear tension spring.

Xerox WorkCentre 4265 Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax, Email
Print Resolution (Max)	Up to 1200 x 1200 dpi
Memory (Standard)	2 GB
Memory (Maximum)	2 GB
Connectivity	10/100/1000Base-T Ethernet, USB 2.0
Paper Output	250 sheets
Scan Resolution (Optical)	Up to 600 x 600 dpi
Fax Speed	33.6 Kbps
Media Sizes Supported	Legal, Letter
Mobile Printing	Apple AirPrint
Duplex Printing	Automatic
Display	7-inch color touchscreen
