January 2016
4-145
WorkCentre 4150/4250/4260WorkCentre WorkCentre 4150/4250/42604150/
REP 9.6
Repairs and Adjustments
3. Remove the Xerographic Connector (Figure 2).
Figure 2 Removing the Xerographic Connector
Replacement
Replacement is the reverse of the removal procedure.
1
Remove the Xerographic
Connector from inside the
Cover.
