Xerox WorkCentre 4265 Service Manual

January 2016
6-4
WorkCentre WorkCentre 4150/4250/4260WorkCentre 4150/4250/
GP 1
General Procedures and Information
4. Touch the Closeout button to complete the exit procedure.
Table 1 Diagnostic menu
1st Level 2nd Level 3rd Level 4th Level
Service Info (GP 11) HFSI Reset / Edit -
- Software Versions - NOTE: Only the categories for the
installed options are displayed.
- Usage Counters Display Usage Counters -
- - Modify Displayed Billing Counters -
- Machine Serial No.: - -
- Images Since Last Call: - -
- Network IP Address: - -
- System Administrator Passcode - -
Fault History Fault Log View Fault Details -
- - Erase History -
- - Order by Time / Order by Code -
- Fault Counters Non Zero Fault Counters / All Fault Counters -
- - Fault Chain 01 Electrical
- - - 03 Run Control
- - - 04 Drives and Fans
- - - 05 DADF
- - - 06 LSU (ROS)
- - - 07 Paper Tray
- - - 08 Paper Feed
- - - 09 Xerography
-- - 10 Fusing
- - - 12 Finisher
- - - 15 Scan to Email
- - - 16 Network Controller
- - - 17 Network
-- - 20 Fax
Diagnostic Routines Copier Routines dC131 NVM Read/Write -
-- dC132 NVM Initialization - Copier All Copier NVM
- - - Machine Variable NVM
- - - SA/KO Dust Off
- - - System Counters Dust Off
-- dC305 UI Test User Interface Button Test
- - - Audio Tone Test
- - - LED Indicator Test
- - - Touch Area Test
- - - Display Pixel Test

Xerox WorkCentre 4265 Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax, Email
Print Resolution (Max)	Up to 1200 x 1200 dpi
Memory (Standard)	2 GB
Memory (Maximum)	2 GB
Connectivity	10/100/1000Base-T Ethernet, USB 2.0
Paper Output	250 sheets
Scan Resolution (Optical)	Up to 600 x 600 dpi
Fax Speed	33.6 Kbps
Media Sizes Supported	Legal, Letter
Mobile Printing	Apple AirPrint
Duplex Printing	Automatic
Display	7-inch color touchscreen
