January 2016
7-58
WorkCentre WorkCentre 4150/4250/4260WorkCentre 4150/4250/
PWB Connectors
Wiring Data
DADF PWB (4250/4260)
Location: PL 5.30 Item 24
Figure 18 DADF PWB (4250/4260)
DADF CCD PWB (4265)
Location: PL 5.70
Figure 19 DADF CCD PWB (4265)
CN2
CN1
1
