7-61
WorkCentre 4150/4250/4260WorkCentre 4150/4250/4260WorkCentre Work-
PWB Connectors
Wiring Data
OPE Sub PWB (4265)
Location: PL 2.14
Figure 24 OPE Sub PWB (4265)
OPE Key PWB (4265)
Location: PL 2.14
Figure 25 OPE Key PWB (4265)
CN1
1
CN1
1
